Диммер, 243EX – Jung

Описание

TRONIC rotary dimmer insert 20 – 360 W
with 2-way push switch

Intended use

• Switching and dimming incandescent lamps, HV halogen lamps and TRONIC transformers with halogen lamps
• Suitable for mixed operation up to the specified output
• Installation in appliance box according to DIN 49073

Product characteristics

• Dimming method: trailing edge phase control
• Electronic short-circuit protection with permanent switch-off after 7 seconds at the latest
• Electronic overtemperature protection
• Satellite switching possible in combination with 2-way switch
• Suitable amplifiers: ULZ 1215 REG and 247 EB (max. 10)
  When using 247 EB, charge dimmer with minimum capacity.

Technical data
Rated voltage: AC 230/240 V ~, 50 Hz
Connected load: 20 ... 360 W (flush-mounted)
20 ... 320 W (surface-mounted)
Dimming method: trailing edge phase control
Type of loads: 230 V incandescent lamps
230 V halogen lamps
TRONIC transformers
Mixed loads of the specified types
Connection: screw terminals
Approvals: VDE

Manufacturer: JUNG
Ref.-no.: 243 EX
